Steel Corrugated Beam Guardrail HA-A1 manufacturer from China Shandong Huaan Traffic Facilities Co.,Ltd

Product Detail

Model No.: HA-A1

Production Capacity: 50000 Metric Ton/Year

Delivery Date: 7-15 days, depend on your q...

Type: w beam/Three waves beam

Material: Q235,Q345

Surface Treatment: Galvanized or Plastic Spray

Feature: Corrossion Resisitant

Means of Transport: Ocean

Packing: Export mill standard packin...

Brand Name: HUAAN

Specification: 4320*310*85*(2.5-4)mm

Standard: JT/T281-1995, AASHTO M-180

Application: Highway,bridge,lakeside,par...

Certificate: IISO9001-2008

Material:Q235,Q345
4320*310*85*4mm
4320*506*85*4mm
highway quality and low parice
Absorb the impact energy by beam deformation

Normal Size	3200/3300/4128/4130/4300/4320×306/310/312/506×80/82/83/85×2.55/2.67/2.75/3/4mm. Available in different sizes.
Profile	W-beam, Three-beam
Applicable Standard	JT/T281-2007(Corrugated Sheet Steel Beams For Expressway Guardrail - China), AASHTO M-180(Corrugated Sheet Steel Beams For Highway Guardrail - USA), RAL-RG620 (German) or any other International Standards.
Material	Steel Grade Q235B (equivalent to S235JR according to DIN EN 10025 and Gr. D according to ASTM A283M) Steel Grade Q345 (S355JR / ASTM A529M 1994).
the Thickness of the Steel	2.55mm, 2.67mm, 2.75mm, 3mm, 4mm Or according to consumers' request.
Surface Treatment	Hot Dipped Galvanized or Powder Coated
the Thickness of Galvanized (double sides)	550g/m2 (80µ) or 610g/m2 (85µ) or 1100 g/m2 (160µ) or 1200 g/m2 (170µ) Or as per your request.
Certificate	ISO9001:2000, ISO14000, SGS, CE
Features	Great corrosion resistant, high intensity, long and durable, with good impact resistance,low cost, long life, higher security, environmental protection, etc.
Relevant parts for Guardrail	Posts, Spacer (C, U and Sigma types etc), Bolts and Nuts and washers, Reflectors and Terminal Ends
Technology	Cold Rolled
Application	Highway and Road safety
Other special specification as per client's requirement or drawings.
